2270                              PRACTICE EXAM SOLUTION Prob 1



1.      (30 points)

a.   Calculate the value of rms current, Irms, flowing through zL.

b.   Calculate the complex power, S, for zL. Include appropriate units.



ans:  a)     Irms = 10 Arms

         b)     S = 100 + j400 VA



sol'n:  (a)   The circuit is a current divider:



sol'n:  (b)

S = 100 + j400 VA
